Valve function
|
4/2 monostable |
|
Actuation type
|
Electrical |
|
Operating pressure [bar]
|
3 to 8 |
|
Control type
|
pilot operated |
|
Flow direction
|
Not reversible |
|
Pneumatic connection 1
|
G1/8 |
|
Pneumatic connection 2
|
G1/8 |
|
Pneumatic connection 3
|
G1/8 |
|
Pneumatic connection 4
|
G1/8 |
|
Construction set up
|
Poppet valve with reset spring |
|
Reset mode
|
Mechanical spring |
|
Protection category
|
IP65 |
|
Sealing principle
|
Soft |
|
Shifting time off [ms]
|
23 |
|
Shifting time on [ms]
|
13 |
|
Medium temperature [°C]
|
-10 to 60 |
|
ambient temperature [°C]
|
-5 to 40 |
|
Housing material
|
Aluminium wrought alloy |
|
Seals material
|
NBR |
|
Hand assist actuation
|
none |
|
Normal nominal flow [l/min]
|
120 |
|
Nominal width [mm]
|
3,5 |
|
Exhaust function
|
Can be throttled |
|
installation position
|
arbitrary |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Bearing temperature [°C]
|
-20 to 60 |
|
Fastening type
|
With throughway bores |
|
Weight
|
230 g / Pcs |
|
GTIN
|
4052568110581 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
