size
|
Mini |
|
Model series
|
DB |
|
Actuation fuse
|
Rotary button with stopper |
|
installation position
|
arbitrary |
|
Construction set up
|
Directly controlled piston control valve |
|
Controller function
|
Output pressure constant |
|
Operating pressure [bar]
|
1.5 to 10 |
|
Pressure regulator range MPa [MPa]
|
0.05 to 0.7 |
|
Pressure regulation range [bar]
|
0.5 to 7 |
|
Max. pressure hysteresis [bar]
|
0,5 |
|
Normal nominal flow [l/min]
|
>= 1000 l/min |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [-:-:-] |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Medium temperature [°C]
|
-5 to 50 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Pressure regulator range psi [psi]
|
7 to 100 |
|
Product weight [g]
|
500 |
|
Fastening type
|
Front panel integration |
|
Pneumatic connection 1
|
G1/2 |
|
Pneumatic connection 2
|
G1/4 |
|
Locking screw material
|
Steel |
|
Spacer bolts material
|
Aluminium wrought alloy |
|
Connection strip material
|
Aluminium wrought alloy |
|
Gasket material
|
PVC |
|
Seals material
|
NBR |
|
Housing material
|
PA reinforced |
|
Weight
|
500 g / Pcs |
|
GTIN
|
4052568178314 |
|
Customs duty number
|
84811099 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Pressure regulators, D series (english) , Data sheet |
