size
|
Maxi |
|
Model series
|
D |
|
installation position
|
vertical ± 5° |
|
Construction set up
|
diaphragm drier |
|
Operating pressure [bar]
|
3 to 12.5 |
|
Normal nominal flow [l/min]
|
300 |
|
Operating medium
|
Air quality class 1:7:1 to DIN ISO 8573-1 |
|
Pressure dew point lowering [°C]
|
-253,15 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-20 to 60 |
|
Medium temperature [°C]
|
2 to 50 |
|
ambient temperature [°C]
|
2 to 50 |
|
Product weight [g]
|
1.800 |
|
Fastening type
|
pipe installation |
|
Housing material
|
Zinc pressure cast |
|
Clamps material
|
Aluminium wrought alloy |
|
Pneumatic connection 1
|
G1/2 |
|
Pneumatic connection 2
|
G1/2 |
|
Weight
|
1.800 g / Pcs |
|
GTIN
|
4052568182175 |
|
Customs duty number
|
84213925 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: LDM1-D (english) , Data sheet |
