Switching position display
|
LED |
|
Fastening type
|
on solenoid valve with central screw M3 |
|
installation position
|
arbitrary |
|
Product weight [g]
|
570 |
|
Electrical connection 1
|
Angled socket, Square shape, 3 pin, C shape |
|
Electrical connection 2
|
Open end, 2-wire |
|
Nominal operating voltage DC [V]
|
24 |
|
Current carrying capacity at 40°C [A]
|
4 |
|
Protection line connection
|
Not available |
|
Cable length [MTR]
|
10,0 |
|
Line properties
|
For static applications |
|
Min. cable bending radius [mm]
|
52 |
|
Cable diameter [mm]
|
5,2 |
|
Tolerance cable diameter
|
± 0,1 mm |
|
Cable set up
|
2x0,75 |
|
Protection category
|
IP67 |
|
ambient temperature [°C]
|
-20 to 80 |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Cable sleeve material
|
PVC |
|
Housing material
|
TPE-U(PU) |
|
Seals material
|
NBR |
|
Plug contacts material
|
Bronze |
|
Weight
|
570 g / Pcs |
|
GTIN
|
4052568079789 |
|
Customs duty number
|
85444290 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: KME (english) , Data sheet |
