installation position
|
arbitrary |
|
Terminal type with effective direction
|
both sides |
|
Operating pressure [bar]
|
3.8 to 8 |
|
Min. loosening pressure [bar]
|
3,8 |
|
Round stock to be clamped [mm]
|
25 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
ambient temperature [°C]
|
-10 to 60 |
|
Static holding force [N]
|
8.000 |
|
Product weight [g]
|
15.600 |
|
Seals material
|
NBR |
|
Spring material
|
High-alloyed steel |
|
Housing material
|
Aluminium wrought alloy |
|
Clamp jaws material
|
tool steel |
|
Piston material
|
Aluminium wrought alloy |
|
Fastening type
|
With female thread |
|
Loose connection clamping unit
|
G3/8 |
|
Safety function
|
Holding and stopping a movement |
|
Max. permitted test pressure [bar]
|
10 |
|
Permission
|
IFA |
|
Weight
|
15.600 g / Pcs |
|
GTIN
|
4052568016036 |
|
Customs duty number
|
84798997 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: KP/KPE/KEC (english) , Data sheet |
