Valve function
|
3/2 bistable |
|
Pneumatic connection 1
|
QS-10 |
|
Pneumatic connection 2
|
QS-10 |
|
Actuation type
|
Manually |
|
Fastening type
|
pipe installation |
|
Normal nominal flow [l/min]
|
780 |
|
Nominal width [mm]
|
7 |
|
Operating pressure [bar]
|
-0.95 to 10 |
|
ambient temperature [°C]
|
0 to 60 |
|
Housing material
|
PBT reinforced |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Exhaust function
|
Cannot be throttled |
|
Sealing principle
|
Soft |
|
installation position
|
arbitrary |
|
Construction set up
|
Piston pusher |
|
Control type
|
Direct |
|
Flow direction
|
Not reversible |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Product weight [g]
|
44,0 |
|
Pneumatic connection 3
|
Not recorded |
|
Material information
|
RoHs compliant |
|
Weight
|
44,0 g / Pcs |
|
GTIN
|
4052568034931 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Ball valves and shut-off valves (english) , Data sheet |
