Model series
|
DB |
|
size
|
Mini |
|
Pitch dimension [mm]
|
44 |
|
Construction set up
|
Switch on valve |
|
Actuation type
|
Manually |
|
Sealing principle
|
Soft |
|
Exhaust function
|
Cannot be throttled |
|
Actuation fuse
|
Padlock (optional) |
|
Hand assist actuation
|
none |
|
Control type
|
Direct |
|
Valve function
|
3/2 bistable |
|
Operating pressure [bar]
|
0 to 10 |
|
C-value []
|
6,3 |
|
b-value
|
0.8 |
|
Normal nominal flow [l/min]
|
2.300 |
|
Normal nominal flow 2-3 [l/min]
|
700 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Material information
|
RoHs compliant |
|
Medium temperature [°C]
|
-5 to 50 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Fastening type
|
pipe installation |
|
Product weight [g]
|
66 |
|
Pneumatic connection 1
|
G1/4 |
|
Pneumatic connection 2
|
G1/4 |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Piston pusher material
|
POM |
|
Seals material
|
FPM |
|
Housing material
|
PA reinforced |
|
Weight
|
66 g / Pcs |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Einschalt-/Druckaufbauventile, Baureihe D , Data sheet |
