Valve function
|
Supply air throttle check valve function |
Pneumatic connection 1
|
PK-4 with union nut |
Pneumatic connection 2
|
G1/8 |
Setting element
|
slotted screw |
Fastening type
|
Screwable |
Normal nominal flow in one-way flow control [l/min]
|
230 |
Normal nominal flow in check valve direction [l/min]
|
190 to 240 |
ambient temperature [°C]
|
-10 to 60 |
installation position
|
arbitrary |
Normal flow In one-way flow control 6 -> 0 bar [l/min]
|
360 |
Normal flow In check valve direction 6 -> 0 bar [l/min]
|
295 to 375 |
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
Medium temperature [°C]
|
-10 to 60 |
Max. tightening torque [Nm]
|
6,0 |
Product weight [g]
|
25,0 |
Stud material
|
Aluminium wrought alloy |
Material information
|
RoHs compliant |
Seals material
|
NBR |
Regulation screw material
|
Brass |
Swivel connection material
|
Zinc pressure cast |
Operating pressure complete temperature range [bar]
|
0.3 to 10 |
Weight
|
25,0 g / Pcs |
GTIN
|
4052568030643 |
Customs duty number
|
84812090 |
RoHS compliant
|
Yes |
Manufacturer
|
Festo |
Document
|
Group data sheet: One-way flow control valves (english) , Data sheet |
