Valve function
|
Throttle blowback function |
|
Pneumatic connection 1
|
M5 |
|
Pneumatic connection 2
|
M5 |
|
Setting element
|
knurled screw |
|
Fastening type
|
Front panel integration |
|
Normal nominal flow in one-way flow control [l/min]
|
95,0 |
|
Normal nominal flow in check valve direction [l/min]
|
75 |
|
Operating pressure [bar]
|
0.5 to 10 |
|
ambient temperature [°C]
|
-20 to 60 |
|
Housing material
|
Aluminium wrought alloy |
|
installation position
|
arbitrary |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-20 to 60 |
|
Nominal width [mm]
|
2 |
|
Product weight [g]
|
37,0 |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Sleeve material
|
POM |
|
Regulation screw material
|
High-alloyed steel |
|
Nut material
|
Aluminium wrought alloy |
|
Weight
|
37,0 g / Pcs |
|
GTIN
|
4052568010881 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
