Valve function
|
Throttle blowback function |
|
Pneumatic connection 1
|
M3 |
|
Pneumatic connection 2
|
M3 |
|
Setting element
|
knurled screw |
|
Fastening type
|
Front panel integration |
|
Normal nominal flow in one-way flow control [l/min]
|
29,5 |
|
Normal nominal flow in check valve direction [l/min]
|
26 to 27.5 |
|
Operating pressure [bar]
|
0.3 to 8 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Housing material
|
Aluminium wrought alloy |
|
installation position
|
arbitrary |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-10 to 60 |
|
Product weight [g]
|
2,5 |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Regulation screw material
|
Brass |
|
Weight
|
2,5 g / Pcs |
|
GTIN
|
4052568009328 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: One-way flow control valves GR/GRA, in-line installation (english) , Data sheet |
