Valve function
|
3/2 bistable |
|
Actuation type
|
Manually |
|
Normal nominal flow [l/min]
|
600 |
|
Operating pressure [bar]
|
-0.95 to 10 |
|
Construction set up
|
Plate seat |
|
Reset mode
|
Mechanical spring |
|
Nominal width [mm]
|
7 |
|
installation position
|
arbitrary |
|
Control type
|
Direct |
|
Flow direction
|
Not reversible |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
ambient temperature [°C]
|
-10 to 60 |
|
actuating force [N]
|
58,5 |
|
Product weight [g]
|
1.760 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection 1
|
G1/4 |
|
Pneumatic connection 2
|
G1/4 |
|
Pneumatic connection 3
|
G1/4 |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium die casting |
|
Weight
|
1.760 g / Pcs |
|
GTIN
|
4052568001704 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valves, manually operated (english) , Data sheet |
