size
|
100 |
Stroke [mm]
|
200 |
installation position
|
arbitrary |
Guide
|
ball guide |
Construction set up
|
Guide |
ambient temperature [°C]
|
-20 to 80 |
Max. force Fy [N]
|
2.300 |
Max. force Fy static [N]
|
3.120 |
Max. force Fz [N]
|
2.300 |
Max. force Fz static [N]
|
3.120 |
Max. torque Mx [Nm]
|
198 |
Max. torque Mx static [Nm]
|
268 |
Max. torque My [Nm]
|
197 |
Max. torque My static [Nm]
|
267 |
Max. torque Mz [Nm]
|
197 |
Max. torque Mz static [Nm]
|
267 |
Pushing force [N]
|
40 |
Product weight [g]
|
14.530 |
Fastening type
|
with female thread |
Material information
|
Copper and PTFE-free |
Guide element material
|
Quenched and tempered steel |
Housing material
|
Aluminium wrought alloy, anodised |
Joch plate material
|
Quenched and tempered steel |
Weight
|
14.530 g / Pcs |
GTIN
|
4052568010003 |
Customs duty number
|
84129080 |
RoHS compliant
|
Yes |
Manufacturer
|
Festo |
Document
|
Group data sheet: FEN/FENG (english) , Data sheet |
