size
|
32 |
|
Construction set up
|
With V-belt |
|
installation position
|
arbitrary |
|
Angle of rotation
|
Endless |
|
Gear ratio
|
3:1 |
|
Product weight [g]
|
3.250 |
|
Actuator pinion diameter [mm]
|
12 |
|
V-belt separation [mm]
|
5 |
|
Max. output speed [Umdrehung ]
|
300 |
|
Max. input speed [Umdrehung ]
|
900 |
|
Max. actuator torque [Nm]
|
8,5 |
|
Empty run actuator torque [Nm]
|
< 0,5 Nm |
|
ambient temperature [°C]
|
-10 to 60 |
|
Material information
|
LABS containing materials included |
|
Housing material
|
Aluminium wrought alloy |
|
Actuator shaft material
|
Aluminium wrought alloy |
|
Drive shaft material
|
High-alloyed stainless steels |
|
Cover material
|
Aluminium wrought alloy |
|
V-belt material
|
Polychloroprene with glass fibre |
|
Weight
|
3.250 g / Pcs |
|
GTIN
|
4052568194390 |
|
Customs duty number
|
84834090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: ERMB (english) , Data sheet |
