مشخصات
عنوان ویژگی |
مقدار ویژگی |
ambient temperature [°C]
|
-10 to 40 |
Bearing temperature [°C]
|
-20 to 70 |
Relative humidity
|
0 - 90 % |
Complies to standard
|
IEC 60034 |
Insulation protection class
|
F |
Measurement class according to DIN 60034-1
|
S1 |
Protection category
|
IP21 |
Electrical connection technology
|
Plug |
Material information
|
LABS containing materials included |
Corrosion resistant class KBK
|
0 - No corrosion stressing |
CE certificate (see declaration of conformity)
|
to EU EMC directive |
Permission
|
RCM mark |
Nominal operating voltage DC [V]
|
565 |
Nominal voltage DC [V]
|
565 |
Winding switching type
|
Star internal |
Standstill torque [Nm]
|
7,50 |
Nominal torque [Nm]
|
6,40 |
Peak torque [Nm]
|
30,0 |
Nominal speed [Umdrehung ]
|
3.000 |
Max. speed [Umdrehung ]
|
3.941 |
Nominal performance motor [W]
|
2.000 |
Continuous standstill current [A]
|
4,6 |
Nominal current motor [A]
|
4,1 |
Peak current [A]
|
18,4 |
Motor constant [Newtonmete]
|
1,561 |
Voltage constant phase-phase [Millivolt ]
|
101,4 |
Winding resistance phase-phase [Ohm]
|
3,2 |
Winding inductivity phase-phase []
|
15,0 |
Total output moment of gyration [Kilogramm ]
|
6,410 |
Product weight [g]
|
7.550 |
Permitted axial shaft loading [N]
|
136 |
Permitted radial shaft loading [N]
|
680 |
Rotor position transducer
|
Encoder absolut single turn |
Rotor position transducer interface
|
HIPERFACE® |
Rotor position transducer measurement principle
|
Capacitive |
Rotor position transducer sinus / cosinus periods per rotation
|
16 |
Rotor position transducer resolution typical [Bit]
|
12 |
Rotor position transducer typical angle precision []
|
20 |
MTTFd, part component
|
340 years, rotor position sensor |
Weight
|
7.550 g / Pcs |
GTIN
|
4052568251536 |
Customs duty number
|
85015220 |
RoHS compliant
|
Yes |
Manufacturer
|
Festo |
Document
|
Group data sheet: EMME-AS (english) , Data sheet |
