Application:
For high-viscosity and crystallised measured material, adjustable zero and span
Materials:
Housing and measured material contacting parts: 1.4571, NBR
Temperature range:
Measured material temperature: -30°C to +100°C, ambient temperature: -20°C to +80°C
Protection class:
IP 65
Connection:
0.25 - 1.6 bar G 1" with O-Ring (NBR), 2.5 - 600 bar G 1/2" with O-Ring (NBR)
Power supply:
10 - 30 V DC, elbow plug DIN 43650 / EN 175301-803 (size 3, 4-pin)
Output signal:
4 - 20 mA
Non-linearity:
± 0,2 % of the span (BFSL)
Accuracy:
± 0,5 % of the span (BFSL)
Transmission fluid*:
Silicone oil
Note:
WIKA Type S-11
