Actuator pinion diameter [mm]
|
8 |
|
Working stroke [mm]
|
0 to 200 |
|
size
|
25 |
|
Angle of rotation
|
Endless |
|
V-belt separation [mm]
|
3 |
|
installation position
|
arbitrary |
|
Gear type
|
V-belt gear |
|
Construction set up
|
With V-belt |
|
Gear ratio
|
4:1 |
|
Max. output speed [Umdrehung ]
|
300 |
|
Max. input speed [Umdrehung ]
|
1.200 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Max. actuator torque [Nm]
|
2,2 |
|
Max. feed force Fx [N]
|
480 |
|
Empty run actuator torque [Nm]
|
< 0,18 Nm |
|
Product weight [g]
|
3.620 |
|
Actuator shaft material
|
Steel |
|
Material information
|
LABS containing materials included |
|
Drive shaft material
|
High-alloyed stainless steels |
|
Cover material
|
Aluminium wrought alloy |
|
Housing material
|
Aluminium wrought alloy |
|
V-belt material
|
Polychloroprene with glass fibre |
|
Weight
|
3.620 g / Pcs |
|
GTIN
|
4052568226831 |
|
Customs duty number
|
84798997 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: EHMB (english) , Data sheet |
