size
|
80 |
|
Required integration diameter [mm]
|
95 |
|
Stroke [mm]
|
20 |
|
Max. height extended [mm]
|
70 |
|
Max. tilt angle [deg]
|
10 |
|
Max. displacement [mm]
|
5 |
|
Min. integration height [mm]
|
50 |
|
Principle of operation
|
single action |
|
Operating pressure [bar]
|
0 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [-:-:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
ambient temperature [°C]
|
-40 to 70 |
|
Reset force [N]
|
400 |
|
Product weight [g]
|
500 |
|
Fastening type
|
with female thread |
|
Pneumatic connection
|
G1/4 |
|
Material information
|
Copper and PTFE-free |
|
Bellows material
|
CR |
|
Housing material
|
Cast aluminium |
|
Weight
|
500 g / Pcs |
|
GTIN
|
4052568255077 |
|
Customs duty number
|
40169991 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: EB (english) , Data sheet |
