Piston diameter
|
63 mm |
|
installation position
|
Condensate discharge downwards |
|
Construction set up
|
With pressure gauge |
|
pressure display
|
with pressure gauge |
|
Output pressure 2 [bar]
|
4 to 16 |
|
Operating pressure [bar]
|
2 to 8 |
|
Pressure regulation range [bar]
|
4 to 16 |
|
Input pressure 1 [bar]
|
2 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:3:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
5 to 60 |
|
ambient temperature [°C]
|
5 to 60 |
|
Product weight [g]
|
21.500 |
|
Fastening type
|
With Cap nuts |
|
Pneumatic connection 1
|
QS-12 |
|
Pneumatic connection 2
|
KD4 |
|
Pneumatic connection 3
|
silencer |
|
Material information
|
RoHs compliant |
|
Volume
|
20 l |
|
Compressed air storage material
|
High-alloyed stainless steels |
|
CE certificate (see declaration of conformity)
|
to EU pressure vessel directive |
|
Max. tightening torque Condensate drain [Nm]
|
27 |
|
Weight
|
21.500 g / Pcs |
|
GTIN
|
4052568194987 |
|
Customs duty number
|
84148080 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: DPA (english) , Data sheet |
