size
|
10 |
|
installation position
|
arbitrary |
|
Construction set up
|
Force controlled movement cycle |
|
Position detection
|
For proximity switch |
|
Operating pressure [bar]
|
3 to 6 |
|
Max. impact speed [m/s]
|
0,8 |
|
Max. swivel time [ms]
|
150 |
|
Repeatability
|
±0.02 mm |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
ambient temperature [°C]
|
0 to 60 |
|
Max. impact force [N]
|
500 |
|
Product weight [g]
|
154 |
|
Fastening type
|
With Throughway bore and centring sleeve |
|
Pneumatic connection
|
M3 |
|
Material information
|
RoHs compliant |
|
Seals material
|
PU |
|
Housing material
|
Aluminium wrought alloy |
|
Lever material
|
High-alloyed stainless steels |
|
Weight
|
154 g / Pcs |
|
Customs duty number
|
84798997 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: DADM-EP (english) , Data sheet |
