installation position
|
arbitrary |
|
Position detection
|
For proximity switch |
|
Operating pressure [bar]
|
2.5 to 8 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
-10 to 60 |
|
Product weight [g]
|
530,0 |
|
Fastening type
|
clamped in DGC cylinder |
|
Pneumatic connection
|
QS-4 |
|
Material information
|
Copper and PTFE-free |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium wrought alloy |
|
size
|
32 |
|
Max. impact speed [m/s]
|
3 |
|
Max. swivel time [ms]
|
100 |
|
Repeatability [mm]
|
0,02 |
|
Limit-stop screw material
|
Steel |
|
Lever material
|
High-alloyed stainless steels |
|
Clamps material
|
High-alloyed stainless steels |
|
Nut material
|
Steel |
|
Fine adjustment [mm]
|
2 |
|
Principle of operation
|
double acting |
|
Weight
|
530,0 g / Pcs |
|
GTIN
|
4052568179786 |
|
Customs duty number
|
84798997 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: DGC (english) , Data sheet |
