size
|
16 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
-10 to 60 |
|
Product weight [g]
|
166 |
|
Fastening type
|
With Throughway bore and centring sleeve |
|
Material information
|
RoHs compliant |
|
Screws material
|
Steel |
|
Settings range swivel angle [deg]
|
60 to 200 |
|
Construction set up
|
Piston |
|
Position detection
|
For proximity switch |
|
Operating pressure [bar]
|
5 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Pneumatic connection
|
M5 |
|
Seals material
|
NBR |
|
Housing material
|
aluminium |
|
Housing cover material
|
aluminium |
|
Bearing material
|
Plastic |
|
Washer material
|
aluminium |
|
Principle of operation
|
single action |
|
Weight
|
166 g / Pcs |
|
GTIN
|
4052568245276 |
|
Customs duty number
|
84123100 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: DRRD (english) , Data sheet |
