Dimensions W x L x H
|
40 mm x 91 mm x 50 mm |
|
Product weight [g]
|
98 |
|
Report
|
Ethernet / IP |
|
Internal cycle time
|
1 ms per 1 byte user data |
|
Max. address volume inputs [Byte]
|
64 |
|
Max. address volume outputs [Byte]
|
64 |
|
Diagnosis
|
Unterspannung |
|
Parameterising
|
Diagnoseverhalten |
|
Additional functions
|
AddressConflictDetection (ACD) |
|
Operating element
|
DIL switch |
|
LED display product specific
|
PS: Operating voltage electronics and load supply |
|
LED display bus specific
|
TP1: Network active port 1 |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Nominal operating voltage DC [V]
|
24 |
|
Intrinsic power input at operating voltage
|
Type 65 mA |
|
Max. power supply [A]
|
4 |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
KC-mark
|
KC-EMV |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Permission
|
RCM mark |
|
Housing material
|
PA |
|
Material information
|
LABS containing materials included |
|
Configuration support
|
EDS file |
|
Fieldbus interface
|
2x Socket M12x1.4-pin, D-coded |
|
Baud rate
|
10/100 Mbit/s |
|
Weight
|
98 g / Pcs |
|
Customs duty number
|
85176200 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CTEU (english) , Data sheet |
