Dimensions W x L x H
|
50 mm x 107 mm x 50 mm |
|
Parameterising
|
Systemparameter |
|
Additional functions
|
Emergency message |
|
Operating element
|
DIL switch |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 100 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
125,0 |
|
Max. address volume outputs [Byte]
|
128 |
|
Max. address volume inputs [Byte]
|
128 |
|
Report
|
EtherCAT |
|
Material information
|
RoHs compliant |
|
Housing material
|
PA reinforced |
|
Fieldbus interface
|
2x Socket M12x1.4-pin, D-coded |
|
Device specific diagnosis
|
Unterspannung Module |
|
Configuration support
|
ESI file |
|
Baud rate
|
100 Mbit/s |
|
LED display bus specific
|
Error: Communication error |
|
LED display product specific
|
PL: Load supply |
|
Weight
|
125,0 g / Pcs |
|
Customs duty number
|
85176200 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
