Dimensions W x L x H
|
50 mm x 107 mm x 50 mm |
|
Diagnosis
|
Unterspannung Ausgänge |
|
Parameterising
|
Failsafe pro Kanal |
|
LED displays
|
1 Sammeldiagnose |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 16 mA |
|
Max. power supply per channel
|
0.5 A (12 W lamp load) |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - internal bus
|
Yes, for intermediate feed |
|
Potential separation channel - channel
|
no |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
Depends on connection block |
|
ambient temperature [°C]
|
-5 to 50 |
|
Housing material
|
PC |
|
Fuse (short circuit)
|
Internal electronic fuse Per channel |
|
Quantity outputs:
|
8 |
|
Max. cumulative current outputs per module [A]
|
4,0 |
|
Characteristic curves outputs
|
IEC1131-T2 |
|
Switching logic outputs
|
PNP (Positive switching) |
|
Weight
|
110 g / Pcs |
|
GTIN
|
4052568007232 |
|
Customs duty number
|
85389091 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
