Dimensions W x L x H
|
50 mm x 107 mm x 50 mm |
|
Diagnosis
|
Parametrierfehler |
|
Parameterising
|
Signalbereich pro Kanal |
|
LED displays
|
1 Sammeldiagnose |
|
Internal cycle time
|
500 µs |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 50 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Potential separation channel - internal bus
|
Yes, without using internal sensor supply |
|
Potential separation channel - channel
|
no |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
Depends on connection block |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
46,0 |
|
Max. line length
|
30 m |
|
Material information
|
RoHs compliant |
|
Housing material
|
PC |
|
Quantity inputs
|
4 |
|
Fuse (short circuit)
|
Internal electronic fuse |
|
Nominal operating voltage DC load voltage
|
24V ± 2% |
|
Repeatability
|
0.1 % at 25 °C |
|
Use error limits related to ambient temperature range
|
± 0.3 % |
|
Base error limit at 25 °C
|
± 0.2 % |
|
Data format
|
15 bit + Sign |
|
Sensor type
|
± 10V |
|
Weight
|
46,0 g / Pcs |
|
GTIN
|
4052568008123 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX-P (english) , Data sheet |
