Dimensions W x L x H
|
50 mm x 107 mm x 55 mm |
|
Diagnosis
|
Parametrierfehler |
|
Parameterising
|
Diagnose Grenzwertüberwachung pro Kanal |
|
LED displays
|
1 Sammeldiagnose |
|
Internal cycle time
|
5 ms |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Intrinsic power input at operating voltage
|
Type 50 mA |
|
Nominal operating voltage DC [V]
|
24 |
|
Corrosion resistant class KBK
|
(In integrated condition) |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Material information
|
RoHs compliant |
|
Housing material
|
PC |
|
Quantity inputs
|
4 |
|
Data format
|
15 bit + Sign |
|
Measured parameter
|
4x Relative pressure / 2x differential pressure |
|
Presentable unit(s)
|
kPa |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
0 to 50 |
|
Pressure measurement range end value [bar]
|
1 |
|
Pressure measurement range starting value [bar]
|
-1 |
|
Pneumatic connection
|
QS-4 |
|
Weight
|
155 g / Pcs |
|
GTIN
|
4052568207168 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPX (english) , Data sheet |
