Nominal width laval nozzle [mm]
|
0,95 |
|
installation position
|
arbitrary |
|
Ejector characteristic
|
High vacuum |
|
Operating pressure [bar]
|
3 to 8 |
|
max. vacuum [%]
|
85 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Medium temperature [°C]
|
0 to 50 |
|
ambient temperature [°C]
|
0 to 50 |
|
electrical connection:
|
Plug |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection 1
|
Connection plate |
|
Pneumatic connection 3
|
Connection plate |
|
vacuum connection
|
G1/8 |
|
Material information
|
RoHs compliant |
|
Housing material
|
Aluminium die casting |
|
Weight
|
110 g / Pcs |
|
GTIN
|
4052568146115 |
|
Customs duty number
|
84141089 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal CPV, Compact Performance (english) , Data sheet |
