Pitch dimension [mm]
|
16 |
|
installation position
|
arbitrary |
|
Max. number of valve spaces
|
9 |
|
Max. number of pressure zones
|
2 |
|
Operating pressure [bar]
|
-0.896317 to 9.99739 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
-5 to 50 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Max. tightening torque Valve fastening [Nm]
|
1,22024 |
|
Product weight [g]
|
380,032 |
|
Fastening type connection block
|
With throughway bores |
|
Fastening type valve
|
with female thread |
|
Pneumatic connection 1
|
NPT1/4-18 |
|
Pneumatic connection 3
|
NPT1/4-18 |
|
Pneumatic connection 5
|
NPT1/4-18 |
|
Material information
|
RoHs compliant |
|
Connection strip material
|
Aluminium wrought alloy |
|
Weight
|
380,032 g / Pcs |
|
GTIN
|
4052568094409 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CPE (english) , Data sheet |
