مشخصات
| عنوان ویژگی |
مقدار ویژگی |
|
Recording range in degrees [deg]
|
0 to 100 |
|
Complies to standard
|
VDI/VDE 3845 (NAMUR) |
|
Short circuit resistance
|
yes |
|
Reverse polarity protection
|
For target value |
|
Display type
|
Backlit LCD |
|
Setting options
|
Via display and buttons |
|
Type of process valve characteristic curves
|
Freely adjustable via 21 support points |
|
Seal wear behaviour
|
adjustable |
|
Adjustment, regulation range
|
adjustable |
|
Effective direction
|
adjustable |
|
Operating pressure [bar]
|
3 to 8 |
|
Target value
|
0 - 20 mA |
|
Safety instructions
|
Safety position: In case of cable break or failure of operating voltage the response is opening/closing |
|
Operating voltage range DC [V]
|
21.6 to 26.4 |
|
Max. load resistance current output [Ohm]
|
500 |
|
Empty run current [mA]
|
90 to 300 |
|
Max. power input [A]
|
1 |
|
Max. output current [mA]
|
500 |
|
Switch level
|
Signal 0: <= 5 V |
|
Size of the dead zone [%]
|
0.5 to 10 |
|
Permission
|
RCM mark |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Protection category
|
IP65 |
|
Medium temperature [°C]
|
-5 to 60 |
|
ambient temperature [°C]
|
-5 to 60 |
|
Cable screwing
|
M20x1,5 |
|
UV resistance
|
yes |
|
Fastening type
|
With Accessories |
|
Product weight [g]
|
970 |
|
Pneumatic connection
|
G1/8 |
|
Normal nominal flow [l/min]
|
50 |
|
Material information
|
RoHs compliant |
|
Housing material
|
PC |
|
Threaded piece material
|
High-alloyed stainless steels |
|
Seals material
|
NBR |
|
Adapter plate material
|
Aluminium |
|
Plate material
|
Aluminium |
|
Cable connection material
|
PA |
|
Bearing temperature [°C]
|
-20 to 60 |
|
Weight
|
970 g / Pcs |
|
Customs duty number
|
90328100 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CMSX (english) , Data sheet |
