CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Protection category
|
IP65 front-side, IP20 rear side |
|
ambient temperature [°C]
|
0 to 50 |
|
Permission
|
C-tick |
|
Material information
|
RoHs compliant |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Nominal operating voltage DC [V]
|
24 |
|
Product weight [g]
|
2.100 |
|
Integration depth [mm]
|
56 |
|
Height [mm]
|
232 |
|
Length [mm]
|
287 |
|
Max. panel front thickness [mm]
|
4 |
|
Realtime clock
|
yes |
|
Event lists
|
2048 |
|
Recipe memory [Byte]
|
32.000 |
|
Sides
|
1000 |
|
Tags
|
10000 |
|
Widget
|
2000 |
|
Objects on one screen
|
2000 |
|
User
|
50 |
|
Simultaneous client access
|
4 |
|
Trend buffer
|
30 |
|
Curves per trend widget
|
5 |
|
Recipes
|
32 |
|
Parameter sets per recipe
|
32000 |
|
Event buffer
|
4 |
|
Events per event buffer
|
2048 |
|
Alarms
|
2000 |
|
Javascript file size per screen [Byte]
|
8.000 |
|
Project size
|
30 |
|
Scheduler
|
30 |
|
Supported PLC protocols
|
CODESYS 2.3 |
|
Deviation realtime clock
|
130 s / month |
|
Quantity system LEDs
|
1 |
|
Display
|
TFT colour |
|
Display properties
|
Touch screen |
|
Display size
|
10.4" |
|
Back-up battery
|
Li battery, rechargeable |
|
Display resolution
|
SVGA, 800x600 pixels |
|
Power input in nominal operating voltage
|
1 A |
|
Relative humidity
|
5 - 85 % |
|
PLC interface
|
Ethernet |
|
USB interface
|
yes |
|
SD card slot
|
1 |
|
Ethernet interface
|
RJ45 10/100 MBd |
|
Fastening type
|
Front panel integration |
|
Programming software
|
Designer Studio |
|
Weight
|
2.100 g / Pcs |
|
GTIN
|
4052568223045 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CDPX (english) , Data sheet |
