Materials:
Body and slider: aluminium, seals: NBR, pilot: polyamide
Temperature range:
-5°C to +60°C
Operating pressure:
1,5 - 8 bar
Media:
oiled and unoiled filtered compressed air
Service life:
min. 40 million switching cycles
مشخصات
| عنوان ویژگی |
مقدار ویژگی |
|
Switching
|
5/3-way |
|
function
|
Centre position closed |
|
Thread
|
G 1/4" (Pilot and exhaust G 1/8") |
|
flow [l/min]
|
600 |
|
A [mm]
|
111 |
|
B [mm]
|
35 |
|
C [mm]
|
22 |
|
D [mm]
|
10,5 |
|
E [mm]
|
36 |
|
F [mm]
|
20 |
|
G1
|
G 1/4" |
|
G2
|
G 1/8" |
|
H1 [mm]
|
4,3 |
|
H2 [mm]
|
3,3 |
|
J [mm]
|
17 |
|
K [mm]
|
27 |
|
L [mm]
|
38 |
|
M [mm]
|
28 |
|
N [mm]
|
36 |
|
O [mm]
|
35,5 |
|
P [mm]
|
3 |
|
S [mm]
|
21 |
|
T [mm]
|
46 |
|
W [mm]
|
0 |
|
Weight
|
210 g / Pcs |
|
GTIN
|
4050571716332 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
EMC |
|
Document
|
Catalogue page Atlas 9, Data sheet |
