Materials:
Body: aluminium, seals: NBR, pilot: polyamide (glass fibre reinforced)
Temperature range:
-10°C to +60°C
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
< 20 ms
Nominal width:
1.1 mm
Control voltage:
Standard: 24 V=, 230 V AC, upon request: other voltages
Voltage tolerance:
± 10 %
Power consumption:
Direct current: 2.5 W, alternating current: 3.5 VA
Protection class (VDE 0470/EN 60529):
IP 65 (IP 40 with rectangular plug SY100)
Solenoid:
L
Scope of delivery:
Valve incl. interlinking accessories and locking screw (for individual use of the valve).
Advantages:
•the seal and screw included in the delivery, multiple valves should be interlinked with each other easily.
Information:
These valves are generally delivered with coils and plugs!
مشخصات
| عنوان ویژگی |
مقدار ویژگی |
|
Control voltage
|
24 V= |
|
Version
|
2-pin plug with LED and protection circuit, including 600 mm cable |
|
function
|
closed (NC) |
|
Thread
|
M 5 |
|
Operating pressure [bar]
|
0 - 8 |
|
flow [l/min]
|
28 |
|
Weight
|
80 g / Pcs |
|
GTIN
|
4050571808365 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
YPC |
|
