Materials:
Body and slider: aluminium, seals: NBR, pilot: polyamide
Temperature range:
-5°C to +60°C
Operating pressure:
1,5 - 8 bar
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
<50 ms, max. 5 switching cycles/sec.
Control voltages:
Standard: 24 V=, 230 V AC, upon request: other voltages
Voltage tolerance:
± 10 %
Power consumption:
Direct current: 4,8 W, alternating current: 5 VA
Protection class (VDE 0470/EN 60529):
IP 65
Solenoid:
T (plug size 1)
Service life:
min. 12 million switching cycles
Advantages:
•Simply by rotating the seal, the valve can be changed between 3/2-way and 5/2-way function •Economical, as the same valve can be used for single-acting drives.
Information:
These valves are generally delivered with coils and plugs!
