Width [mm]
|
43,0 |
|
Length [mm]
|
107,3 |
|
Max. number of valve spaces
|
24 |
|
Valve island structure
|
Valve sizes mixable |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Control pressure [bar]
|
3 to 8 |
|
Corrosion resistant class KBK
|
3 - severe corrosion stress |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
190,00 |
|
Material information
|
RoHs compliant |
|
Max. number of valve coils
|
24 |
|
Nominal operating voltage DC [V]
|
24 |
|
Protection category
|
IP67 |
|
Information about protection category
|
in assembled condition |
|
Electrical connection 1, function
|
multi-pin |
|
Electrical connection 1, connection type
|
Plug |
|
Electrical connection 1, connection technology
|
Sub-D |
|
Electrical connection 1, number of pins / wires
|
25 |
|
End plate material
|
Aluminium die casting |
|
Weight
|
190,00 g / Pcs |
|
GTIN
|
4052568055844 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal MPA-L (english) , Data sheet |
