Width [mm]
|
59,6 |
|
Length [mm]
|
107,3 |
|
Pitch dimension [mm]
|
14,9 |
|
Valve size [mm]
|
14 |
|
Max. number of valve spaces
|
4 |
|
Flow direction
|
Reversible |
|
Valve island structure
|
Valve sizes mixable |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Control pressure [bar]
|
3 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
3 - severe corrosion stress |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
130,80 |
|
Pneumatic connection 2
|
For hose exterior diameter 1/4" |
|
Pneumatic connection 4
|
For hose exterior diameter 1/4" |
|
Material information
|
RoHs compliant |
|
Connection plate material
|
PA reinforced |
|
Max. number of valve coils
|
4 |
|
Weight
|
130,80 g / Pcs |
|
Customs duty number
|
|
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal MPA-L (english) , Data sheet |
