Product weight [g]
|
92,0 |
|
Material information
|
RoHs compliant |
|
Width [mm]
|
20,2 |
|
Length [mm]
|
107,3 |
|
Pitch dimension [mm]
|
10,5 |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Control pressure [bar]
|
3 to 8 |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
ambient temperature [°C]
|
-5 to 50 |
|
Pneumatic connection 2
|
M7 |
|
Pneumatic connection 4
|
M7 |
|
Connection plate material
|
Aluminium die casting |
|
Pneumatic connection 1
|
M7 |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
KC-mark
|
KC-EMV |
|
electrical connection:
|
M8 |
|
Fastening type connection plate
|
With throughway bores |
|
Pneumatic connection 3
|
M7 |
|
Pneumatic connection 5
|
M7 |
|
Support air control connection 12/14
|
M5 |
|
Exhaust control connection 82/84
|
M5 |
|
ATEX gas category
|
II 3G |
|
Ex ignition protection type gas
|
Ex nA IIC T4 X Gc |
|
Ex ambient temperature
|
-5°C <= Ta <= +50°C |
|
Weight
|
92,0 g / Pcs |
|
GTIN
|
4052568257248 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VMPA1 (english) , Data sheet |
